Focus on providing solutions for outdoor digital media and LED industrial applications
| Place of Origin: | China |
|---|---|
| Brand Name: | Sysolution |
| Certification: | FCC，CE certification |
| Model Number: | SY60 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | One piece of equipment per box. Accessories include: 1 USB cable, 1 DVI cable, 1 VGA cable, and 1 HDMI cable |
| Delivery Time: | 2-3 working days |
| Payment Terms: | T/T,PayPal |
| Supply Ability: | 30 units per week |
| Input Voltage: | AC-100-240V-50/60HZ | Power Rate: | 25Watt |
|---|---|---|---|
| Operating Temperature: | 0℃ ~ 45℃ | HDMI In: | 2 |
| VGA In: | 1 | DP: | 1 |
| DVI: | 1 | ||
| Highlight: | led asynchronous controller,cascading card |
||
Input
Three video signal inputs: HDMI 2.0×1, DP 1.2×1 (Choose One of Two); HDMI 1.4×1; supports 3840×2160@60Hz resolution input.
Output
6 network ports output, supports a loaded resolution of 3.9 million pixels.; maximum width supports 15360 pixels, maximum width supports 7680 pixels.
control
Supports RS232 serial port and network control protocol.
Supports USB and LAN network debugging methods
Supports screen management software control
Main application scenarios: Superior visual experience, convenient operation, and excellent cost performance. It offers significant advantages for entertainment venues such as bars and KTV.
| Basic parameters | ||
| Load capacity | single network port | 655,360 pixels; maximum width/height of a single network port is 4096. |
| Full card | 3.9 million pixels | |
| Output resolution |
1. The number of pixels should be controlled within 3.9 million. 2. Widest:15360 Highest:7680 |
|
| Input resolution | Supports video source input with a maximum resolution of 3840×2160@60Hz, and is backward compatible. | |
| Video source format | |||
| Input Interface | Dark color | Maximum input resolution | |
| HDMI2.0 | 8-bit | RGB4:4:4 | 3840×2160@60Hz |
| YCbCr4:4:4 | |||
| YCbCr4:2:2 | |||
| YCbCr4:2:0 | |||
| HDMI1.4 | 8-bit | RGB4:4:4 | 3840×2160@30Hz |
| YCbCr4:4:4 | |||
| YCbCr4:2:2 | |||
| DP1.2 | 8-bit | RGB4:4:4 | 3840×2160@60Hz |
| YCbCr4:4:4 | |||
| YCbCr4:2:2 | |||
<img alt="" src="/photo/sysolution/editor/20260817172535_31459.jpg <h3><span style=" color:#0000ff;"="">Cautions:
1. Commissioning and installation must be completed by professionals;
2. Non-professionals are not allowed to disassemble the machine for maintenance;
3. Pay attention to anti-static;
4. Pay attention to waterproofing.
