Focus on providing solutions for outdoor digital media and LED industrial applications
| Place of Origin: | China |
|---|---|
| Brand Name: | SYSOLUTION |
| Certification: | CE, FCC, ROSH |
| Model Number: | M70B |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Carton Box |
| Delivery Time: | 10 days |
| Supply Ability: | 100pcs per 1 month |
| Working Voltage （V）: | 12V DC | Working Current （A）: | 0.9A Max： 3A |
|---|---|---|---|
| Warranty: | 1 Year | Dimensions: | 178mmx129mm |
| Display Technology: | LED | Operating System: | Android7.1 |
| Working Temperature: | -30~75℃ | Storage: | 2GB+16GB |
| HDMI Output: | 1 HDMI Output | Communication: | 4G,WIFI,Ethernet |
| Audio: | 3.5mm Audio Port | Net Weight: | 1300g |
| Dimension: | 217（L）x135（W）x44（H） |
Functional Features:
Product Parameters
| Features | Description | |
| Type | M70B(No 4G)/M70B-4G Control box, M70-4G Naked card | |
| Pixel | M70B:Synchronous/Asynchronous Media player Dual Ethernet ports,1.3 million pixels, maximum width 1920,maximum height 1920,Support discount maximum width 20222,maximum height 1920 | |
| Communicati on mode | Network port,WiFi,USB,optional 4G module | |
|
System memory |
16GB Emmc+2GB LPDDR3 | |
| Operating syste | Android 7 | |
| WiFi | IEEE 802.11b/g/n 2.4G | |
| GPS | GNSS GPS/Beidou/Glonass | |
|
Other interface support |
1. 1.1 channel stereo audio output. 2. 1 line HDMI input 3. 1 USB2.0 port. 4. Support play program through USB. 5. 1 RS485 port, 1 RS232,1 TTL serial port. Connect to light sensor or other sensors, as well as connecting to other modems to realize other functions. |
|
| Configuration software | LedOK Express | |
| Support frequency band | ||
| Type | 3G/4G(optional) | Certificate |
|
M70B-CH |
-China(China/India) FDD-LTE: B1/3/5/8
TDD-LTE: B38/39/40/41
TDSCDMA: B34/39
WCDMA: B1/8
CDMA 1X/EVDO: BC0
GSM: B3/5/8 |
Compulsory Certification:SRRC/ NAL/ CCC
Others:WHQL |
|
M79B-G |
-Global
FDD-LTE: B1/2/3/4/5/7/8/12/13/
18/19/20/25/26/28
TDD-LTE: B38/39/40/41
WCDMA: B1/2/4/5/8/6/19 GSM:4 Frequencies |
Operator certification: Deutsche
Telekom/ Verizon/ AT&T/ Sprint/U.S. Cellular/ Telus
Mandatory/consistent
authentication:GCF/ CE/ FCC/ PTCRB/ IC/ Anatel/IFETEL/ SRRC/ NAL/ CCC/
KC/ NCC/
JATE/ TELEC/ RCM/ NBTC/
IMDA/ICASA
Others:WHQL |
|
M70B-NA |
-North America
FDD-LTE: B2/4/5/7/12/13/17
WCDMA: B2/4/5 |
Operator certification:AT&T/
T-Mobile/Rogers/ TelusVerizon/AT&T (FirstNet)/T-Mobile/U.S.
Cellular/Rogers/ Telus Mandatory/consistent
authentication: FCC/ IC/ PTCRB
Others:WHQL |
|
M70B-EU |
-Eurasi(EMEA/Korea/Thailand/India and other Asian countries)
FDD-LTE: B1/3/5/7/8/20
TDD-LTE: B38/40/41
WCDMA: B1/5/8
GSM: B3/5/8 |
Operator certification:
Vodafone/Deutsche Telekom/SKT/
Telefónica
Mandatory/consistent
authentication: GCF/ CE/ KC/ NCC/RCM/ FAC/ NBTC/ICASA
Others:WHQL |
|
M70B-LA |
-Latin America(LA/AU/Newsland) FDD-LTE: B1/3/5/7/8/28
TDD-LTE: B40
WCDMA: B1/2/5/8
GSM: B2/3/5/8 |
Compulsory Certification: GCF/ FCC/ Anatel/ NCC/RCM
Others:WHQL |
|
M70B-J |
-Japan
FDD-LTE: B1/3/8/18/19/26
TDD-LTE: B41
WCDMA: B1/6/8/19 |
Operator certification: NTT DOCOMO/SoftBank/ KDDI
Compulsory Certification:JATE/ TELEC
others:WHQL |
| Working Parameters | ||
| Power Input(V) | 5~12V 1~3A | |
| Working Temperature(°C) | -30~75℃ | |
| Working Humidity (%) | 0%~80% RH | |
| Stock Temperature (℃) | -40~80℃ recommend 5~35℃ | |
| Dimension (mm) | 217(L)x135(W)x44(H) | |
| Weight (g) | 1300g | |
