Focus on providing solutions for outdoor digital media and LED industrial applications
| Place of Origin: | China |
|---|---|
| Brand Name: | SYSOLUTION |
| Certification: | RoHs and CE-EMC certification |
| Model Number: | Receiving card |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 units per Month |
| LED Module: | Full Color | Update Firmware: | Support |
|---|---|---|---|
| Standard: | Meet The ROHS Standard | Pixels: | One Card Can Support 256x256 Pixels Maximum |
| Press TEST Button To Test: | Support | LED Module Scan Types: | Support Random Scan Types Within 32 Scans |
| High Light: | led receiver card,receiving card led display |
||
LED Receiving Card D90-A43
Product Features:
Sysolution D90-A4S is new product with tiny size but high standard universal receiving card, it has following features:
Technical Parameters:
| Features options | Typical value | Maximum value | |
| Supported screen type | Single/dual/full color screens real/virtual pixel | ||
| Supported receiving card quantity, cascading by single network cable | <1000 | 1000 | |
| Supported resolution by one receiving card | 128*128 | 96K pixels | |
| RGB output group of one receiving card | 26 | 26 | |
| Lines of one set of RGB driver | 1/2/4/8/16/32 | 1~32 | |
| Optical fiber transmit distance |
Multi-mode optical fiber: 500Meters; single module optical fiber: 10KM |
||
| Other features | 10b video source, LED display self-detecting, OE protection | ||
| Working current | 0.6A | 1.0A | |
| Working temperature | -10℃ - 65℃ | ||
| Extreme working temperature | -20℃ - 75℃ | ||
| Working humidity (%) | 0%-95% | ||
