1. 1.18Bit+: Enabling 18Bit+on the software can increase the grayscale of LED displays by 4 times, effectively addressing the issue of grayscale loss caused by reduced brightness in LED displays, solving the problem of pockmarks caused by low gray correction, and making the low gray image more delicate.

2. HDR: Supports both HDR10 and HLG video source standards; paired with a high-capacity independent main controller, when inputting HDR10 or HLG standard video sources, it can achieve a wider brightness dynamic range and color space, greatly enhancing the display quality and making the picture more delicate and realistic.

3. 3. Low latency: Reduce the latency of the video source at the receiving card end, achieving a latency as low as 1 frame (for light boards using driver ICs with built-in RAM)

4. 4. Quick brightness and dark line adjustment: Quickly adjust the brightness and dark lines on the software to quickly solve the display screen brightness and dark lines caused by box and module splicing. The adjustment process takes effect immediately and is simple and easy to use.

5. 5.3D Function: Receive card parameter setting frame rate of 120HZ, in conjunction with an independent controller that supports 3D function, enable 3D function on the software or independent controller's operation panel, and set 3D parameters to display 3D effects on the screen.

6. 6. RGB independent gamma adjustment: In conjunction with an independent controller and software that supports RGB independent gamma adjustment, the "red gamma", "green gamma", and "blue gamma" can be adjusted separately to effectively control issues such as uneven low gray and white balance drift on the display screen, making the image more realistic.

7. 7. Support color correction on a per light basis: With the help of calibration software, the brightness and chromaticity of each light point on the large screen are corrected, effectively eliminating color differences and achieving high consistency in brightness and chromaticity of the display screen, thereby improving the image quality of the display screen.

8. 8. Support multiple display effect schemes: in conjunction with LedSet4.0 software, achieve refresh priority and grayscale priority effects.

9. 9. Support 90 ° multiple rotation of the screen: In conjunction with LedSet4.0 software, it can rotate the receiving card screen by 90 ° multiple.

10. Support for screen zoom function: With LedSet4.0 software, the pixels loaded on the receiving card can be zoomed in and out multiple times, achieving the enlargement and reduction of the display screen.

1. 1. Support receiving card number detection: With the network port debugging function in LedSet4.0 software, the receiving card number and network port information will be displayed on the target box, and users can know the location number and connection line of the receiving card.

2. 2. Support data interface customization: With LedSet4.0 software, it can detect and edit the output data of the receiving card.

3. 3. Support for constructing complex enclosures: In the advanced layout of LedSet4.0 software, enclosure modules can be quickly arranged and constructed arbitrarily.

4. Support for constructing complex large screens: In the LedSet4.0 software's complex display screen connection, the box can be quickly arranged and constructed arbitrarily.

1. 1. Support receiving card configuration parameter read back: The current receiving card configuration parameters can be read back on LedSet4.0.

2. 2. Support for network cable error rate detection: On LedSet4.0, real-time monitoring of the network cable communication signal quality of the system hardware connection can be carried out to quickly determine the quality of the network cable and eliminate faults.

3. Communication monitoring function: Real time monitoring of the working status of the receiving card on LedSet4.0.
