Place of Origin: | China |
---|---|
Brand Name: | Sysolution |
Certification: | FCC,CE certification |
Model Number: | RP3 |
Minimum Order Quantity: | 1 |
Price: | Negotiation |
Packaging Details: | carton box |
Delivery Time: | 2-3 working days |
Payment Terms: | T/T,PayPal |
Supply Ability: | 30 units per week |
Powe Dissipation: | Basic: 20W; Max: 32W | Operating Temperature: | -40℃ - +70℃ |
---|---|---|---|
Operating Humidity: | ≤95% | Level Of Protection: | IP67, TVS 8000V |
Size: | 382.0*240.0(diameter)mm | Net Weight: | 5.8kg |
Type | Parameters |
Camera | |
Type | RP3 |
Sensor type | 1/1.9 inches CMOS |
Pixels | 200,0000 |
Maximum resolution | 1920×1080 |
Electronic shutter | 1/1s~1/30000s |
Minimum illumination | colorful:0.001Lux@F1.5 white and black:0.0001Lux@F1.5 0Lux(enable infrared light) |
Maximum fill distance | 220m(infrared) |
Fill lamp control | Magnification priority / manual /SmartIR/ off |
Number of fill lamps | 10numbers(Infrared lamp) |
Fill light type | Infrared |
Camera lens | |
Focal length | 5.8mm~191.4mm |
Lens aperture | F1.5~F4.8 |
Field angle | horizontal:60.1°~ 3.2° vertical:35.3°~1.8° diagonal:67.9°~3.7° |
Optical zoom | 33X |
Close range | 0.1m~1m |
Zoom speed | About 4.9s |
Pan tilt | |
Rotation range | Horizontal:0°~360°continue rotate vertical:-20°~+90°Auto flip180°then keep monitoring |
Keying speed | Horizontal:0.1°/s~200°/s Vertical:0.1°/s~53°/s |
Preset point speed | Horizontal:240°/s Vertical:128°/s |
Preset point | 300 numbers |
Cruise control | There are 8 lines, can add 32 preset points for each line. |
Automatic tracking | 5 lines |
Automatic line scanning | 5 lines |
Power off memory | support |
Idle action | Line scan; Cruise; Patrol; Preset |
PTZ agreement | DH-SD Pelco-P/D(Auto recognition) |
Scheduled task | Line scan; Cruise; Patrol; Preset |
Preset point video freezing | Support |
positioning | Support |
Visual domain function | Support |
Professional intelligence | |
Intelligent classification | Special intelligence |
Illegal parking | Capture distance radius: 140m (multi scene) and 66m (single scene) support abcd illegal parking capture; Support adaptive multi scene cruise detection; It supports vehicle type, body color, vehicle logo, vehicle series, license plate, license plate color and other motor vehicle attribute recognition. |
Bayonet snap | It supports the coverage of 1 motor vehicle lane +1 non motor vehicle license plate, and supports the detection and capture of the following behaviors: Car checkpoints, white line pressing, yellow line pressing, retrograde, illegal lane changing, vehicle congestion, vehicle occupation, yellow card occupation, non following Lane driving, over speed, under speed, not wearing seat belts, and traffic congestion; Support the following vehicle feature recognition: license plate, license plate color, body color, vehicle type, vehicle logo, vehicle line, vehicle speed, annual inspection mark, tissue box, perfume box, pendant, seat belt status, sun visor status, face matting, driver smoking status, and driver calling status. |
Electronic police | It supports the coverage of 1 motorway +1 non motorway license plate. It supports the detection and capture of the following behaviors: Vehicle bayonet, white line, yellow line, retrograde, illegal lane change, vehicle congestion, vehicle occupation, yellow card occupation, non following Lane driving, over speed, illegal U-turn, illegal reverse, failing to yield to pedestrians, and non following guide arrows. It supports the identification of the following vehicle characteristics: license plate, license plate color, body color, vehicle type, vehicle logo, and vehicle line |
Intelligent description | The three intelligence, i.e. illegal stop snapshot, checkpoint snapshot and electronic police, are mutually exclusive and support time-sharing reuse of intelligent multi scene cruise. |
Video | |
Video compression standard | MJPEG;H.264H;H.264M;H.264B;Smart H.264;H.265;Smart H.265 |
Default code stream at default resolution | 4096Kbps(1920×1080) |
Video frame rate | 50Hz Main code stream(1920×1080@50fps),Main code stream(1280×960@50fps),Main code stream(1280×720@50fps) Secondary code stream1(704×576@25fps),Secondary code stream1(352×288@25fps) Secondary code stream2(1920×1080@25fps),Secondary code stream2(1280×960@25fps),Secondary code stream2(1280×720@25fps),Secondary code stream2(704×576@25fps),Secondary code stream2(352×288@25fps) 60Hz main code stream(1920×1080@60fps),main code stream(1280×960@60fps),main code stream(1280×720@60fps) Secondary code stream1(704×480@30fps),Secondary code stream1(352×240@30fps) Secondary code stream2(1920×1080@30fps),Secondary code stream2(1280×960@30fps),Secondary code stream2(1280×720@30fps),Secondary code stream2(704×480@30fps),Secondary code stream2(352×240@30fps) |
Bitstream control | Variable bitstream / fixed bitstream |
Day night conversion | ICR Automatic switching / electronic color to black |
Backlight compensation | Support |
Wide dynamic | Support |
Glare suppression | Support |
The white balance | Automatic / indoor / outdoor / tracking / manual / sodium lamp / natural light / street lamp |
Gain control | Auto / manual |
Noise reduction | 2D noise reduction /3d noise reduction |
Areas of interest ROI | Support |
Shake Reduction | Electronic anti shake |
Fog penetration function | Electronic fog transmission |
Digital zoom | 16X |
Privacy masking | Up to 24 areas, and up to 8 areas on the same screen, supporting 8 colors |
Signal to noise ratio | ≥55dB |
Audio | |
Audio compression standard | G.711a;G.711Mu;AAC;G7221;G726;MP2L2;G729 |
Network | |
Network interface | 1(RJ-45Network port,support 10M/100Mnetwork data) |
Network protocol | TCP;PPPoE;RTP;RTCP;ARP;IGMP;SNMPv1/v2c/v3(MIB-2);SNMP;ICMP;UPnP;FTP;Qos;802.1x;IPv6;DDNS;DNS;DHCP;NTP;SMTP;UDP;RTSP;IPv4;HTTPS;HTTP |
Access standard | SDK;CGI;GB/T28181;ONVIF |
Preview maximum users | 20个(total band width:64M) |
Storage function | AIPS4.0;SD Card |
Browser | Support ie:ie7 and above; Support Google: no version limit; Support Firefox: no version limit; Apple support: no version restrictions |
Functions | |
SVC | Time domain |
Area focusing | Support |
OSD Information Superposition | Access; Time; Preset point; Temperature; PTZ coordinates; Zoom; Due north; Geographical location; picture |
Safe mode | Authorized user name and password; MAC address binding; HTTPS encryption; IEEE802.1x; Network access control. |
User management | Support 19 users at most; Multi level user permission management |
Interfaces | |
RS-485 Port | 1(baud rate range:1200bps~9600bps) |
Audio input | 1 line(LINE IN;naked cable) |
Audio output | 1 line(LINE OUT;naked cable) |
Alarm interface | 7 in and 2 out |
Voice intercom | Support |
Alarm input | 7 lines,Switching value input(0~5V DC) |
Alarm output | 2 lines |
Alarm linkage | Snapshot; Preset point; Cruise; Patrol; Video recording; Trigger switching value output; Send mail |
Alarm events | Dynamic detection / video occlusion; Audio detection; Network disconnection detection; IP conflict detection; Memory card status detection; Storage space detection |
Power | |
Power supply | AC24V/3A±25%(standard) |
Consumption | Basic consumption:20W maximum consumption :32W(Fill light on) |
Environment | |
Working temperature | -40℃~+70℃ |
Working humidity | ≤95% |
Degree of protection | IP67;TVS 8000V Lightning protection, surge protection and surge protection |
Structure | |
Size | 382.0mm×Φ240.0mm(height×diameter) |
Net weight | 5.8kg |
Gross weight | 8kg |
Installation type | Wall mounting; Hoisting; Pole installation; Cross bar assembly |
Accessories | Standard power supply: with adapter block: with optional wall mounting: dh-pfb306w wall mounting: dh-pfb303w+ adapter block hoisting: dh-pfb300c+ adapter block upright mounting: dh-pfa150+dh-pfb303w+ adapter block crossbar mounting: dh-pfa150+dh-pfb300c+ adapter block |
Filter items | |
Ball machine size | 6 inches |
Interfaces type |
RS485 port; RJ45 port |
H.265 | Support |
Starlight level | Super star light |
Other features | Illegal parking; Electronic police; Vehicle structure |
